Thermal Camera Core is an advanced 640x512 infrared camera core powered by 12μm microbolometer array technology, which is designed for a variety of applications requiring high sensitivity and excellent image quality. The camera core features an extension component of VPC/ USB3.0/ GigE/ CameraLink, and its size is 44.45mm x 44.45mm x 26mm. With a weight of 67g, this thermal camera core offers a spectral range from 8μm to 14μm with a frame rate of 50Hz. This thermal camera core is an ideal choice for applications requiring superior image quality and sensitivity.

Features:

• Thermal Module: Thermal Camera Core
• Uncooled IR Detector: Uncooled Focal Plane Arrays
• Spectral Range: 8μm To 14μm
• Working Voltage: 4V~6V
• Frame Rate: 50Hz
• Weight: 67g

Technical Parameters:

Applications:

GSTiR Thermal Camera Core is an infrared camera core designed to provide accurate and reliable thermal imaging. With its Model Number PLUG612, this thermal camera core comes with a resolution of 640×512 and a size of 44.45mm×44.45mm×26mm. It also has a frame rate of 50Hz and a manual focus. The Uncooled Focal Plane Arrays sensor is highly sensitive to infrared radiation and allows for precise thermal imaging.

GSTiR Thermal Camera Core is widely used in many industries, such as automotive, firefighting, security, medical, electrical, industrial and more. It is a perfect tool for troubleshooting and preventive maintenance, as well as for monitoring temperature changes in hazardous areas. The thermal camera core is also used to detect thermal anomalies in buildings and to detect heat sources inside walls, ceilings, roofs, and other structures.

GSTiR Thermal Camera Core is ideal for inspecting electrical components and systems, such as circuit boards, motors, wiring and connections. It can also detect water ingress and moisture in buildings, walls and other structures. The thermal camera core is also highly effective for detecting pests, such as rodents, termites, and other insects.

GSTiR Thermal Camera Core is a reliable and affordable thermal imaging solution that is designed to meet the highest standards of accuracy and performance. With its high resolution, frame rate, and manual focus, this thermal camera core is the perfect tool for industrial, commercial, and medical applications. It is also highly suitable for use in areas where safety is a priority. Minimum Order Quantity is 1.
